SPECIFICATIONS
VESSEL TYPE: Refrigerated Cargo Ship
CLASS: Set Norske Veritas (DNV) (GL number 21770)
IMO: 8912132
CALL SIGN: C6WH8
MMSI: 311289000
TONNAGE: 7,743 GT / 3,726 NT / 7,726 DWT
LENGTH: 131.25 metre LOA
BEAM: 19.6 metre
DRAFT: 12.85 metre
CREW: 28-persons
BUILD YEAR: 1992 February (28)
Builder: Boelwerf Temse, Belgium
CLASSIFICATION
CLASSIFICATION SOCIETY: Set Norske Veritas (DNV) (GL number 21770)
MAIN CLASS SYMBOLS: +1A1 Reefer (-30dC/32dC Sea) Container PET E0
SERVICE NOTATIONS: +Refrigerated cargo ship
NAVIGATION NOTATIONS: Unrestricted Navigation
MACHINERY: +MACH
CAPACITY
SPEED: 18.0-kn ave / 20.5 max
CONSUMPTION: 16-ton/day (14.5 kts)
RANGE: n mile
BUNKERS
RMG380 (IFO380) 963 mt
DMA (MGO) 107 mt
REEFER
HOLDS: 3
HATCHES: 3
COMPARTMENTS: 12
TEMPERATURE ZONES: 7
COOLING SECTIONS: 1A | 1BC | 1D | 2AB | 2CD | 3AB | 3CD
TEMPERATURE RANGE: -30 / +15
AIR CIRCULATION [/hr] 90
AIR RENEWALS [/hr] 2.4
USDA equipped Yes, valid until 1-October-2019
FREEZING: No
FEU’s 45 Empty / 30 Max
TEU’s 89 Empty / 54 Max
CARGO
FROZEN FISH (-30’C): 5,900-ton
HOLD 1: 1,500-ton
HOLD 2: 2.200-ton
HOLD 3: 2,200-ton
LIVE FISH:
HOLD 1: 50-ton / 80-tank
HOLD 2: 0
HOLD 3: 120-ton / 160-tank
FROZEN FISH (-60’C): 780-ton
FEU DECK: 26
DECK EQUIPMENT:
CARGO GEAR: 1x Crane x 34.0 mt or 17.0 in high speed modus
3x Pallet Cranes x 8.0 mt
REEFER PLUGS: 29 Electrical reefer plugs
ENGINEERING
MAIN ENGINE: 11,013 BHP, B&W Mitsui Engineering & Shipbuilding Co Ltd.,7S50MC, 123rpm
GENERATOR: 4 x 620kW 220/440V 60Hz a.c.
